NO.
하중계수
(Load factor)
허용하중
(Load capacity)
kg
lbs
1
65
240
520
2
75
300
660
     ■ 하중계수 - 완충작용을 하는 Special rubber의 경도 (Share A 65, - Share A 75)



개당 허용하중 (Load capacity/pce)
100 kg (220 lbs)
4개당 추천하중 (Recommended load/4 pcs)
240 ~ 300 kg (520 ~ 660 lbs)
자중 (Net weight)
S-type
1.3 kg (2.9 lbs)
F-type
1.4 kg (3.1 lbs)
사용온도 (Temperature range)
-10 ~ +90℃(+14 ~ +194℉)



① 취부판 (Top plate)
Forged steel
② 몸체 (Frame)
Aluminum diecasted
③ 다리(Leg)
Aluminum diecasted
④ 베어링 (Bearing)
Ball bearing #608zz
⑤ 스프링(Spring)
Special rubber
⑥ 바퀴 (Wheel)
Polyurethane/Anti-static polyurethane with aluminum core
⑦ 잠금장치 (Stopper)
Nylon-6
⑧ 취부볼트 (Mounting bolt)
S-type
M12x1.75P
F-type
4-M6x1.0P
⑨ 표면처리 (Surface treatment)
Powder coated & Zinc galvanized
