NO. |
하중계수
(Load factor) |
허용하중
(Load capacity) |
|
kg |
lbs |
|
1 |
65 |
300 |
660 |
|
2 |
75 |
1,000 |
2,200 |
|
| ■ 하중계수 - 완충작용을 하는 Special rubber의 경도 (Share A 65, - Share A 75) |
|
|
|
|
|
|
개당 허용하중 (Load capacity/pce) |
350 kg (770 lbs) |
|
4개당 추천하중 (Recommended load/4
pcs) |
300 ~ 1,000 kg (660 ~ 2,200
lbs) |
|
자중 (Net weight) |
S-type |
3.2 kg (7.0 lbs) |
|
F-type |
3.5 kg (7.7 lbs) |
|
사용온도 (Temperature range) |
-10 ~ +90℃(+14 ~ +194℉) |
|
|
|
|
|
|
① 취부판 (Top plate) |
Forged steel |
|
② 몸체 (Frame) |
Aluminum diecasted |
|
③ 다리(Leg) |
Aluminum diecasted |
|
④ 베어링 (Bearing) |
Ball bearing #6202zz |
|
⑤ 스프링(Spring) |
Special rubber |
|
⑥ 바퀴 (Wheel) |
Polyurethane/Anti-static polyurethane with aluminum
core |
|
⑦ 잠금장치 (Stopper) |
Aluminum |
|
⑧ 취부볼트 (Mounting bolt) |
S-type |
M16x2.0P |
|
F-type |
4-M10x1.5P |
|
⑨ 표면처리 (Surface treatment) |
Powder coated & Zinc galvanized |
|
|
|
|
|
|
|
